Polyester complete equipment

Capacity：25 t/d～225 t/d

It can be divided into cotton type, wool type, medium length, hollow and compound (hollow is mainly silicone oil three-dimensional crimp and hollow staple fiber).

According to the strength of ordinary and high strength low stretch, according to the size of coarse denier, ordinary, fine denier, super fine denier;

According to the function of ordinary, differentiated, functional fiber.

Spinning machine

Capacity: 25～225 t/d

Applicable product:
The production line is suitable for polyester bottle flakes, slicing, direct melt spinning, according to different fiber cross sections for the production of 0.89 ~ 22.2 dtex polyester staple fiber.

Draw stand II

Capacity：25 t/d～225 t/d

The machine has five rolls, seven rolls, nine rolls and so on, and the pressure roller has up pressure, down pressure and so on.

Annealer

Application：

Finalize the fiber tension state, drying the front area, finalize the rear area. The roller has two types of siphon and jacket, which can meet different heating media such as saturated steam, heat conduction oil and hot water.

Crimper

Capacity：Maximum of 225 t/d

The continuous supply of straight wire bundles is sent into the crimping box by a pair of upper and lower crimping rollers, and the main pressure of the crimping roller and the back pressure of the crimping box are adjusted to make the wire bundles get uniform crimping. Continuous rotation of the sealing side plate of the crimp box improves the quality of the tow.

Cutter

Capacity：Maximum of 150 t/d

Baler

Capacity：Maximum of 225 t/d

The machine delivers machine, electricity, liquid, air and air, and integrates the five steps of conveying, packing, laying, bundling and discharging into one, realizing efficient automatic packing.
